STERIPRO PE SERIES PES MEMBRANE FILTERS
PE SERIES PES MEMBRANE FILTERS
PE SERIES PES MEMBRANE FILTERS
Request a Quote

Steri-PRO PE series Polyether sulfone Sterilizing grade

PES Membrane Filters

are manufactured to conform with the stringent quality standards required by filters that come in contact with biological, pharmaceuticals and other critical processes. The PES Sterile filters conform to Toxicity tests, meet the requirement of USP 29 Biological test for Plastics, and PES Membrane Filters manufactured using components that comply with CFR 21 regulations. The

PES Sterile filters

are supported by a validation guide prepared specifically for manufacturers requiring product documentation as part of their qualification process.
Filter Specification:
Media 0.2 um Double layer Asymmetric PES membrane
Micron Rating 0.45, 0.6, 0.8 and 1.0 micron
Support Media Polypropylene
Cage/Core/End Caps Polypropylene
'O'Rings / Gaskets Buna N, EPDM, Silicone, Viton
Internal Support Ring Stainless Steel
Dimensions
Nominal Lengths 9.75, 10, 20, 30, 40 inches
Outside Diameter 2.7 inches (69mm)
Inside Diameter 1 inch (25.4mm)
Operating Conditions
Max.Diff.Pressure 4 Bar at 20°C/2 Bar at 60°C
Sterilization Autoclave 30 minutes at 126°C. Steam 30 Mins at 121°C
Features & Benefits:
  • Pharmaceuticals
  • Biological
  • Solvents
  • Ophthalmic Solutions
  • LVP/SVP/Sterile API
  • Vaccines
  • High Purity Chemicals
  • High Purity Water
  • Wines
