High-intensity permanent rare earth neodymium magnets for liquid filtration systems.
TRINITY Rare Earth Magnets are ideal for removing ferrous, carbide fines from various Process Fluids. These Magnets are designed to remove ferrous particles in sub-micron size, smaller than that can be extracted by traditional filters. The removal of these particles result in longer fluid life, improved surface finish of products, increased component accuracy and reduced wear & tear on machinery and tools.
Trinity Rare Earth Magnets are permanent magnets made from neodymium-boron-iron (NdFeB). These magnets are the strongest type of permanent magnets made, producing significantly stronger magnetic fields than other magnets. Trinity Rare Earth Magnets don't use consumables & hence contamination is quickly and easily removed as a 'cake' that can be easily disposed of as scrap without losing expensive fluids.
| Technical Specifications | |
|---|---|
| Type | Rare Earth Neodymium (NdFeB) |
| Diameter | 25 mm Standard |
| Length | Standard to suit filter bag size (Size 1 & Size 2) |
| Grade | N40 (Higher grades available) |
| Surface Magnetic Induction (at poles) | 9,300 to 10,200 Gauss (measured with Hall Probe Gauss meter) |
| Sleeve Material | SS 304, SS 316 (optional) |
| Lifting Hook | SS 304, SS 316 (optional); hook at one end of 30 mm diameter |
| Locator Pin | SS 304, SS 316 (optional); pin at another end of 8 mm diameter |
| Magnetic Field Strength Application Guide | |
| 1500 Gauss | Relatively coarse (>50 micron) ferromagnetic iron of abrasion |
| 2500 Gauss | Fine (<50 micron) ferromagnetic iron of abrasion |
| >9000 Gauss | Fine paramagnetic contaminants and sub-micron fines |
Our filtration application engineers work directly with your plant specifications to size the ideal filter media, micron rating, and vessel configurations.
