Advanced felt media filter bags meeting the most critical applications.
TRINITY Flow-PURE series bag filter are manufactured using the advanced felt media meeting the most critical clients applications. Available in three different types of media and a wide range of removal ratings make Flow-PURE Bag Filters are one of the most reliable products available in the marketplace today. Fully welded bags with an option of selecting three different performance grades like Standard Liquid Grade, Standard mesh Grade and High-efficiency Grade makes it an ideal choice for any filtration application.
| Felt Materials | Polypropylene, Polyester, Nylon Mono Filament, High Efficiency Polypropylene, High Efficiency Polyester |
| Removal Ratings | 1, 3, 5, 10, 25, 50, 75, 100, 150, 200, 250, 300, 400, 600, 800, 1000 µm (depending on media) |
| Maximum Operating Temperature | Polypropylene – 80°C; Polyester – 135°C; Nylon – 115°C |
| Maximum Flow Rate | Size 1 – 300 LPM; Size 2 – 570 LPM |
| Maximum Forward Differential Pressure | 20 PSID |
| Recommended Change-out DP | 15 PSID |
| Bag Sizes | Size 1: 7" dia × 16" L | Size 2: 7" dia × 32" L | Size 3: 4" dia × 8" L | Size 4: 4" dia × 14" L | Size 5: 4" dia × 20" L |
| Collar Options | Plastic collar, Standard steel ring, Stainless steel ring |
Our filtration application engineers work directly with your plant specifications to size the ideal filter media, micron rating, and vessel configurations.
